A20009 - 74F377N Octal D Flip-Flop with Enable (Signetics)
The 74F377N is a high-speed 8-Bit Register. The register consists of eight D-Type Flip-Flops with individual D inputs and Q outputs. The common buffered clock (CP) input loads all flip-flops simultaneously when the Enable (E) is LOW. This device is supplied in a 20-pin package.
Features:
High Impedance NPN Base Inputs for Reduced Loading (20 mA in HIGH and LOW States)
Ideal for Addressable Register Applications
Enable for Address and Data Synchronization Applications
Eight Edge-Triggered D Flip-Flops
Buffered Common Clock
20 pin DIP. Manufactured by Signetics.
A20009
Features:
High Impedance NPN Base Inputs for Reduced Loading (20 mA in HIGH and LOW States)
Ideal for Addressable Register Applications
Enable for Address and Data Synchronization Applications
Eight Edge-Triggered D Flip-Flops
Buffered Common Clock
20 pin DIP. Manufactured by Signetics.
